Crimped Wire Mesh

Wire Materials: Carbon iron wire, galvanized steel wire and stainless steel wire.
Weaving Patterns: Woven after crimped
General Use: Screening in mine, coal factory, construction and other industries. Some galvanized crimped wire mesh and stainless steel crimped wire mesh products are used for roasting flour food and meat.



Specification List of Crimped Wire Mesh/Wire Mesh for Roast

Wire Gauge
SWG

Wire Diameter
mm

Mesh/Inch

Aperture
mm

Weight
kg/m²

14 2.0 21 1 4.2
8 4.05 18 1 15
25 0.50 20 0.61 2.6
23 0.61 18 0.8 3.4
24 0.55 16 0.1 2.5
24 0.55 14 0.12 4
22 0.71 12 0.14 2.94
19 1 2.3 0.18 1.45
6 4.8 1.2 2 20
6 4.8 1 2 20
6 4.8 0.7 3 14
14 2.0 5.08 0.3 12
14 2.0 2.1 1 2.5
14 2.0 3.6 1.5 1.9
